uAvionix Corporation company
Certified UAV Communications, Navigation, Control, Surveillance, and Combat ID Solutions
uAvionix Corporation overview
uAvionix was founded with the mission of bringing safety solutions to the unmanned aviation industry to aid in the integration of Unmanned Aircraft Vehicles (UAV) into National Airspace Systems (NAS).
uAvionix offers low SWaP TSO-certified and uncertified avionics for civil UAS, Urban/Advanced Air Mobility (UAM/AAM), General Aviation (GA), airport surface vehicles, and tactical Identification Friend or Foe (IFF) markets. uAvionix is backed by investors at Playground Global and Airbus Ventures.
Jump to section:
Defense Solutions
Mode 5 Combat ID / IFF Solutions for Tactical UAV
Our RT-2087/ZPX IFF (Identification Friend or Foe) solutions provide secure Combat ID with Modes 1, 2, 3/A, C, S, and 5 interoperability for tactical UAS. The low-SWaP systems are installable on UAVs as small as Group 1 or Group 2.
Engineered to the highest standards, ZPX systems have been tested to meet rigorous environmental and performance specifications, with AIMs Mk XIIB certification pending. ZPX transponders are also compliant with civil airspace requirements as Mode S/1090ES ADS-B transponders, simplifying aircraft configurations.
All ZPX Transponders are crypto-appliqué compatible and contain internal crypto emulators to provide non-classified Mode 5 testing and demonstration capability.
Mode S UAV Transponders
ZPX-A – Mode S Transponder with ADS-B for military & civilian UAS
The ZPX-A is a Mode S transponder with ADS-B capabilities, designed to allow both military and civilian UAS to safely operate in controlled airspace. The AIMS-certified transponder can be recognized by other aircraft with Traffic Collision Avoidance Systems (TCAS) or ADS-B In receivers.
The low-SWaP transponder weighs just 50 grams and can be used by UAS as small as Group 1 and Group 2. Capabilities for military users include control of X-bit in Mode A replies and individual on/off mode control.
IFF Combined Transponder-Receivers
RT-2087/ZPX – IFF Mode 5 Transponder with Mode S and ADS-B (UAS Groups 1-5)
RT-2087/ZPX is the world’s lowest-SWaP AIMS Certified Combat ID and Air Traffic Control surveillance transponder.
Designed to satisfy IFF Transponder, Mode S, and ADS-B requirements, RT-2087/ZPX allows tactical UAS to operate in both battlefield conditions and controlled civil airspace.
The secure system can be combined with a micro-crypto appliqué for the latest NATO Mode 5 encryption capabilities. Options include an integrated ADS-B receiver and ethernet connectivity.
ZPX-1 – Combat ID IFF Mode 5 transponder with ADS-B
The ZPX-1 is a Mode 5 transponder designed to satisfy IFF Transponder and ADS-B requirements for tactical UAS that may operate both on the battlefield and in controlled civil airspace. The low-SWaP transponder weighs just 91 grams and can be used by UAS as small as Group 1.
The unit can be combined with a microcrypto system to enable the latest NATO-approved IFF encryption standards.
Learn more: IFF Mode 5 UAV Transponders
IFF Receivers
ZPR – passive Mode 5 IFF and ADS-B receiver system
The ZPR is a passive Mode 5 L2/2B IFF and civil 1090 MHz ADS-B receiver system designed to provide enhanced situational awareness and detection of aircraft operating either in civilian airspace or on the battlefield.
The low-SWaP unit includes an internal crypto emulator and is ideal for installing in aircraft and vessels as well as portable and permanent ground control stations.
Learn more: Mode 5 IFF UAV Receivers
Civil Solutions
Mode S ADS-B OUT Transponders
ping200X – Certified UAV Mode S Transponder with ADS-B OUT
- FAA TSO Certified
- 1090MHz Mode S Transponder
- ADS-B OUT
- Weight: 50 grams
- Size: 47 x 54 x 9 mm
ping200X is the premier FAA TSO Certified Mode S ADS-B OUT transponder for UAS.
Enabling airspace access, regulator, and Air Navigation Service Provider (ANSP) acceptance worldwide, ping200X enables your aircraft to be detected by Secondary Surveillance Radar (SSR), Traffic Collision Avoidance Systems (TCAS), and ADS-B IN receivers.
Compact and light, ping200X is a Level 2els, Class 1 transponder small enough to fit on Class 1 and 2 sUAS. Don’t let the size fool you. At only 50-grams, the ping200X transponder packs a punch delivering 250 watts of transmit power while drawing only 1.5 watts.
ping200X is easily integrated with a wide range of drone autopilots for dynamic control from the ground control station (GCS), with an industry-standard serial protocol and physical protocol converters for broader adaptation. The unit can also be integrated as a “set-and-forget” payload paired with the uAvionix mini-controller.
Pair ping200X with our high-performance truFYX SBAS GPS to deliver safe separation information to Air Traffic Control (ATC) as required for controlled airspace around the globe. The Source Integrity Level (SIL) 3 GPS also guarantees visibility to certified avionics in other aircraft.
Learn more: ping200X – Mode S UAV Transponder with ADS-B OUT
ping200XR – Mode S ADS-B UAV Transponder with Integrated GPS
- FAA TSO Certified
- 1090MHz Mode S Transponder
- ADS-B OUT
- Weight: 52 grams
- Size: 47 x 72 x 10 mm
ping200XR combines our TSO-certified ping200X transponder with an internal TSO-certified GPS, providing aviation-grade avionics performance for UAS with a power consumption of only 1.5 Watts.
The integrated SBAS GPS receiver meets the performance requirements of RTCA DO-229D and TSO-C145e, providing Source Integrity Level (SIL) 3 operation and guaranteeing visibility to certified avionics in other aircraft as well as Air Traffic Control.
ping200X can be easily integrated with a wide range of drone autopilots for dynamic control from the ground control station (GCS), with an industry-standard serial protocol and physical protocol converters for broader adaptation. The unit can also be integrated as a “set-and-forget” payload when paired with our mini-controller.
Learn more: ping200XR – Mode S ADS-B UAV Transponder with Integrated GPS
ADS-B Receivers
pingRX Pro – Detect and Avoid ADS-B UAV Receiver
pingRX Pro is a dual-band ADS-B receiver purpose-built for professional UAV Detect and Avoid (DAA) applications.
- Dual-band (978MHz / 1090MHz) ADS-B IN
- Weight: 8 grams
- Size: 32 x 31 x 9 mm
Capable of tracking aircraft on both 978MHz and 1090MHz, the rugged aviation-grade solution provides superior performance and flexibility for any UAS application, enabling BVLOS approval around the world.
Featuring a maximum range of nearly 100 times that of any competitive solution, pingRX Pro provides true 360×360 awareness, tracking any potential threats at all times and capable of handling up to 100 aircraft simultaneously.
PingRX Pro can be easily integrated with Ardupilot and PixHawk-based drone autopilots, requiring only a few lines of code to be launch-ready.
Learn more: pingRX Pro – Detect and Avoid ADS-B UAV Receiver
pingStation 3 – Ground-Based Networkable Dual-band ADS-B Receiver
- Dual-band (978MHz / 1090MHz) ADS-B IN
- Networkable
- Integrated GPS
- Weatherproof
pingStation 3 is a weatherproof dual-band (978MHz and 1090MHz) ADS-B receiver designed for both permanently-mounted and roaming applications.
It provides ground, surface, or low-altitude ADS-B surveillance within line-of-sight of the antenna up to 200NM away. Multiple pingStations can be networked together to provide a wide area low-altitude surveillance capability.
The integrated GPS receiver provides position and precision time-stamping for multilateration and messaging. Data messages are available in multiple formats for easy integration into custom applications.
The robust unit, housed in an IP67-rated protective enclosure, provides easy mounting and installing, requiring only a single Power-Over-Ethernet (POE) cable for power and data communications.
Learn more: pingStation 3 – Ground-Based Dual-band ADS-B Receiver
GPS Position Sources
truFYX – high-integrity drone GPS receiver
- TSO-C145e certification-pending
- Weight: 20 grams
- Size: 47.37 × 8.21 mm
truFYX is a TSO-C145e certification-pending GPS receiver providing high-integrity aviation-grade position source data for drone autopilot and ADS-B systems.
With reliable performance far exceeding that of a consumer-grade GPS, truFYX is ideal for a range of critical UAS applications such as UAM (urban air mobility), precision agriculture, and search and rescue.
The flexible GPS receiver leverages the same advanced fault detection and exclusion technology used by thousands of manned aircraft around the world. truFYX has been designed to adapt with the growing UAS industry and satisfy current and future regulations and mandates. The device has been developed to DO-178 and DO-254, tested to DO-160G environmental standards, and manufactured in an FAA-approved facility.
truFYX weighs just 20 grams and can be easily integrated into almost any drone configuration. It uses industry-standard NMEA or MavLink protocols and is compatible with a wide range of UAS autopilots.
Learn more: truFYX – high-integrity drone GPS receiver
BVLOS UAV C2 Data Links
microLink – UAV data link for BVLOS command & control
microLink is a Beyond Visual Line of Sight (BVLOS) Command and Control (C2) drone data link radio specifically designed for long-range mission-critical applications and UAV operations.
The FCC (U.S.A.) and IC (Canada)-approved high-integrity avionics solution consists of two radios, each with their own external antenna for enhanced reliability, range, and signal blockage protection.
The GPS timing-synchronized datalink utilizes advanced frequency-hopping techniques to protect against external interference, using the full 902 – 928MHz spectrum range. Performance can be optimized even further by pairing microLink with our skyStation Ground Radio System (GRS), which multiplies your effective range to 12 miles line-of-sight and can be mounted on your GCS or on permanent infrastructure.
The versatile solution features an open architecture with almost limitless integration options and allows you to interface with PixHawk or nearly any serial-connected drone autopilot.
microLink is supplied with a mission monitor application that provides continuous connection status, signal integrity, and health of both ARS and GRS radios, allowing pilots to make critical decisions before link loss occurs.
Learn more: microLink – UAV data link for BVLOS command & control
SkyLine Command & Control Infrastructure and Datalinks
Enterprise UAS C2 infrastructure management service
SkyLineis a scalable Enterprise Command and Control (C2) infrastructure management service that has been designed from the ground up to meet aviation design standards for critical UAS and UAM (urban air mobility) applications.
Vertically Integrated Highly Scalable Infrastructure
It provides real-time statistics and telemetry such as aircraft location, network health and signal strength, all accessible from the cloud.
Cloud-accessible Real-time Statistics and Telemetry
Based around our low-SWaP DO-362A SkyLink datalink radios, SkyLine provides seamless management of your UAS missions and infrastructure. The system has been developed to Design Assurance Level (DAL) C for both hardware and software, ensuring the highest level of safety for unmanned aircraft and cargo.
SkyLine Airborne & Ground Radio Links
Our SkyLine airborne and ground radio systems enable robust Control and Non-Payload Communications (CNPC) links for UAS, and are designed to RTCA DO-362A and FAA TSO-C213a. The radio links provide reliable low-latency transfer of critical information for certifiable LOS and BVLOS missions.
Learn more: SkyLine Command & Control Infrastructure and Datalinks
pingRID – FAA-compliant Remote ID Broadcast Module
pingRID is a compact and lightweight addon module that enables any drone to achieve compliance with the FAA’s Remote ID regulations. The easy-to-use module comes preconfigured right out of the box, requiring you only to assign your unique device ID to your FAA drone registration.
The self-powered design can operate for over 2 hours on a single charge, and can be recharged via USB-C. A set of LED indicators provides at-a-glance status on the battery charge, device readiness for flight, and inflight operations.
Learn more: pingRID Remote ID Broadcast Module
Casia G
Ground-based detect-and-alert system for airspace protection
Casia G is an AI and computer vision-powered surveillance system that provides ground-based monitoring of the airspace, ensuring that your UAS operations are safe from aerial threats. The passive system does not require FCC approval and provides constant 360-degree detection, classification and alerting of all types of aircraft.
Multiple Casia G nodes can be networked together to provide extended coverage, and can be integrated with existing situational awareness systems to enable the Remote Pilot in Command (RPIC) to access all information in a single place.
Learn more: Casia G Airspace Surveillance System
Casia I
Onboard collision avoidance for BVLOS UAS
Casia I is an advanced detect-and-avoid solution for UAS, utilizing cutting-edge machine learning and computer vision technologies to provide real-time aircraft detection and classification. The low-SWaP system can be easily integrated with a wide range of multirotor, fixed-wing and VTOL drones, and is compatible with leading commercial drone autopilots.
Casia I features a 98.9% detection rate and allows drones to reliably and autonomously navigate around obstacles and hazards, ensuring safer and more reliable drone operations.
Learn more: Casia I Detect-and-Avoid System
