11″ ZEUS DIGITAL
Long-range, modular, and field-ready UAV for reconnaissance and delivery missions.
Product descripton: 11″ ZEUS DIGITAL by Summa Defence
A reliable solution for long-range military operations. Ideal for reconnaissance or delivery missions where a stable signal and extended endurance are critical. The kit includes a 6S4P battery and a mounting system for convenient use in field conditions.
Available in optical control (digital) and radio control versions.
- Optical control: Range determined by a fibre coil, starting at 5 km till 45 km with a payload of 3 kg. Cruising speed approximately 15 m/s.
- Radio control: Top speed up to 28 m/s (approximately 125 km/h), yet excellent handling and efficiency. Payload 4–5 kg and range over 20 km.
Technical specifications
ZEUS DIGITAL SPECIFICATIONS
| Parameter | Value |
|---|---|
| Flight Range via Fiber Optic | From 15 km (depending on spool) |
| Maximum Takeoff Weight | Up to 7 kg |
| Maximum Payload Capacity | Up to 3 kg |
| ESC | One ESC for four motors |
| Dimensions (W / L / H) | 790 × 670 × 330 mm |
Main Battery Specifications
| Parameter | Value |
|---|---|
| Capacity | 20,000 mAh |
| Type | Li-Ion |
| Power Connector | XT-60H-F, Cable: 12AWG (optionally XT-90 & 10AWG) |
| Balancer Connector | JST-XH 2.54, Cable: 22AWG |
| Charge Current | 2A (max 4A); Operating Temp: 0 – +45°C |
| Discharge Current | 135A, Pulse (up to 5 sec.): 170A; Temp Range: -40 – +60°C |
| Weight | 1790 g |
Zeus Digital Components
| Component | Details |
|---|---|
| Motor | Armada 3115 900KV |
| Flight Stack | Armada F405 V1, 65A AM32 3-6S |
| Battery Straps | Included |
| Propeller Set | 11x7x3 |
| Day/Dusk Camera | 1/2.8″ 5.0MP CMOS IMX335 |
| Sensitivity | 0.00001 LUX |
| Resolution | 2592×1944 @ 25 FPS |
Kit Contents
| Item | Description |
|---|---|
| FPV Drone | Zeus Digital |
| Frame | Fiberglass laminate |
| Battery | 6S4P, 1 unit |
| Universal Mount | Included |
| Fiber Optic Module | 15 km range |
Fiber Optic Spool Specifications
| Parameter | Value |
|---|---|
| Range | 15–25 km fiber spools |
| Spool Angle | 35° |
| Weight | 1883 g |
| Body Length | 465 mm |
| Body Diameter | 125 mm |
| Connector Type | SC |
| Mount Compatibility | Universal mount |
