ARDAL
Tracked UGV for Logistics and Casualty Evacuation
Product descripton: ARDAL by Burevii
ARDAL is a tracked Unmanned Ground Vehicle (UGV) developed by BUREVII to support logistics and casualty evacuation missions in challenging battlefield environments. Designed for reliable off-road mobility and remote operation, ARDAL helps reduce personnel exposure to hostile conditions while transporting supplies or evacuating wounded personnel. The platform features a multi-channel communication architecture that ensures stable control and operational flexibility, including support for satellite communications and airborne relay operation.
Key Features
- Tracked platform optimized for rough terrain
- Designed for logistics support and casualty evacuation
- Remote operation via multiple redundant communication channels
- Supports satellite and radio communications
- Compatible with airborne communication relay for extended operational range
- Built for reliable military field operations
Technical specifications
| Parameter | Specification |
|---|---|
| Drive Motors | 2,000 W |
| Tracks | Reinforced cast tracks |
| Dimensions (Operational) (L × W × H) | 1,100 × 1,080 × 1,360 mm |
| Dimensions (Transport) (L × W × H) | 1,100 × 1,080 × 700 mm |
| Maximum Speed | 14 km/h (limited) |
| Vehicle Weight | 275 kg |
| Recommended Payload | 150 kg (maximum up to 250 kg on the UGV platform) |
| Trailer Towing Capacity | Up to 300 kg |
| Maximum Range (150 kg payload) | 50 km |
| Maximum Climbing Angle | 30° |
| Maximum Trench Crossing | Up to 800 mm |
| Maximum Vertical Obstacle | 300 mm |
| Communication Channels | Up to 4 channels |
| IP Communication | 2 IP channels (including one Starlink channel) |
| Radio Communication | 2 radio channels |
| Airborne Relay Support | Yes |
| Remote Control | Multi-channel remote operation |
