Atobá
Product descripton: Atobá by Stella Tecnologia
The Atobá UAS is a cutting-edge aerial platform available in versions with MTOW ranging from 500 kg to 700 kg. With its exceptional payload capacity and 28-hour flight endurance, the Atobá is ideal for border surveillance and monitoring of large geographical areas. This combination of high performance and long operational persistence enables the execution of complex and challenging missions with efficiency and precision.
General Overview
The Atobá is a next-generation Medium-Altitude Long-Endurance (MALE) Unmanned Aerial System (UAS) engineered for tactical and strategic operations. With a 700 kg maximum takeoff weight, it delivers extended endurance of 24 hours and up to 160 kg payload, making it a mission-critical asset for intelligence, surveillance, reconnaissance (ISR), electronic warfare (EW), weapons systems, and beyond.
Key Capabilities:
• Operational Reach: Secure dual data-link system (radio up to 300 km, satellite for global connectivity)
• Payload Versatility: Supports gimbal-mounted ISR payloads (up to 50 kg) or fuselage and wing integrated systems (160 kg)
• Autonomous Reliability: Triple-redundant flight control system ensures fully autonomous takeoff/landing
• Scalable Command & Control: Ruggedized Ground Control Station (GCS) enables multi-aircraft coordination and seamless control handover
The Atobá is a force multiplier, enhancing situational awareness, operational reach, and mission flexibility in contested and complex environments.
Technical specifications
| Characteristics | Specifications |
|---|---|
| Wing span | 11 m |
| Length | 8 m |
| Engine | 112 HP |
| Fuel | AVGAS |
| Payload capacity | 160 kg |
| Ceiling | 24,000 ft |
| Endurance | 24 h |
| Cruise speed | 65 kt |
| Take-off and landing | 400 m |
| Maximum Takeoff Weight (MTOW) | 700 kg |
Equipment
Front mounted gimbal (up to 50 kg) or center and wing mounted equipment (up to 160kg) Triple redundant flight computer – capable of autonomous take-off and landing – Radio data-link (300 km range) or sat-com (unlimited range).
