The CK25 drone electrical version (hybrid version optional) is a 100% electrical drone with high payload capacity up to 10kg with a choice of batteries options upon mission.
General specifications: Folded dimensions : 770 × 580 × 720 mm Engine centre distance : 1510 mm Maximum take-off weight : 25 kg standard; up to 28 kg Maximum payload : 10 kg Maximum speed : 21 m/s Battery life : 60 minutes without payload upon battery selection Maximum data link distance : 10 km (standard), up to 30 km optional Telemetry and video frequency : 2.4 – 2.5 GHz (other options available) Emergency telemetry + kill switch frequency : 868 MHz (other options available) Maximum data link distance : 10 km (standard), up to 30 km as an option
Domain | professional |
Applications | surveillance, agricultural, transport, civil defense, heavy lift, for the construction industry, security |
Type | quadcopter |
Engine type | electric motor |
Maximum load |
10 kg |
Autonomy |
Max.: 60 min Min.: 60 min |
Maximum altitude |
Max.: 5,000 m Min.: 3,500 m |
