Selected by Bavovna, for integration

DeltaQuad Evo

Industry-leading long range drone for military, government, and enterprise applications.

Product descripton: DeltaQuad Evo by DeltaQuad

Long range drone

Evolved aerial autonomy

The future of insight is unmanned: An eye in the sky provides heightened perspective and increased efficiency in mapping and surveying. Similarly, long distance drones are transforming modern battlefields with their ISTAR capabilities and ability to transport critical goods rapidly.

DeltaQuad Evo redefines long range drone capabilities with 270 km range and 4.5 hour flight time. Built to the highest military-grade standards, it delivers unmatched performance for defense and commercial missions.

Evo’s dual payload capacity enables multiple missions in a single flight. Evo empowers users to expand their vehicle’s functionality without vendor lock-in constraints. Catering to the needs of the world’s most ambitious drone operators, Evo is a future-proof solution for an constantly evolving industry.

Fully autonomous missions

Evo can perform complex missions with minimal pilot intervention. These range from ISTAR and stealthy supply transport to insight-gathering, mapping, monitoring, and surveying. Evo stays on top of every mission, even when outside communication range of up to 270 km.

Advanced aerodynamics

Evo’s patented wing shape ensures striking manoeuvrability and efficient flight performance. This makes Evo a best-in-class long distance drone, flying up to 4.5 hours.

Dual swappable payloads

Evo’s modular payload system enables maximum insight and rapid field adaptation for a vast range of sensors, automation, or customization options. Operate two sensors simultaneously or extend flight time with an additional battery.

Aerospace grade airframe

Produced with the highest quality carbon, kevlar, and fibreglass. This provides an extremely robust, lightweight airframe that will last for years, even in the harshest conditions.

Powered by Auterion

By running on Auterion’s advanced OS and mission control software, Evo becomes more widely deployable. Pilots familiar with Auterion-powered systems can operate the Evo without additional specialized training, significantly reducing operational costs.

Retractable landing gear

Evo automatically extends and retracts the landing gear. This allows a diverse set of payloads to be installed both inside and underneath the platform while simplifying take-off and landing in congested areas.

5 minute quick deployment

Easy to unpack, assemble, and flight plan. Evo is in the air and collecting data in five minutes, providing pilots with the ability to deploy rapidly.



Technical specifications

Evo general platform specifications

Dimensions

Wingspan 269 cm
Length 75 cm
Height 33 cm (landing gear extended)
Wing area 84 sq. dm
Flight case dimensions 112 x 82 x 46 cm
Payload bay dimensions 20 x 20 x 11 cm

Evo weight and payload

Empty weight 4.8 kg
Empty weight including 1 battery 6.8 kg
Maximum takeoff weight 10 kg
Payload capacity 3 kg

Flight characteristics with dual battery

Flight speed 16.54 m/s (60 km/h)
Payload capacity 1 kg
Maximum flight time
272 minutes (4 hours 32 minutes)
Range through air 270 km (168 mi)

Power

Battery type Semi Solid State Lithium-ion
Battery cells 6
Battery capacity 22 Ah per battery

Tolerances *

Maximum takeoff/landing wind 12.5 m/s (45 Km/h)
Maximum wind cruise flight 14 m/s (50 Km/h)
Maximum precipitation 7 mm/h (Drizzle)
Operating temperature Between -20 and +45 Celsius
Maximum flight altitude AMSL 5500 m

All flight characteristics are based on optimized settings at sea level

These values assume 90% battery usage, and low wind conditions and include a low-altitude vertical takeoff and landing at sea level.

* Tolerances are provisional and subject to change
