FPV VB 140 Flamingo
Product descripton: FPV VB 140 Flamingo by Vinnytski Bdzholy
The VB 140 Flamingo is a next-generation fixed-wing FPV drone designed for long-range missions and heavy payloads. With a wingspan of 1488 mm, it combines aerodynamic efficiency with operational precision. The drone is equipped with an initiation board to ensure controlled and reliable activation of onboard systems, including explosive payloads if required.
VB 140 Flamingo uses a high-quality data transmission protocol based on ExpressLRS (ERLS) at 915 MHz, with customizable frequency settings. It supports analog video transmission systems operating at 5.8 or 1.2 GHz, ensuring stable and clear visuals even over long distances. Engineered for endurance and performance, it can stay airborne for up to 80 minutes and carry a payload of up to 2 kg — making it ideal for reconnaissance, strike missions, and delivery operations. Built to operate in temperatures ranging from -15°C to +40°C, the Flamingo is a versatile and reliable platform in diverse conditions.
Technical specifications
| Specification | Value |
|---|---|
| Maximum Payload | ≥ 2.0 kg |
| Max Flight Altitude with Payload | ≥ 3500 m |
| Cruising Speed with Payload | 70 km/h (±20 km/h) |
| Max Speed with Payload | ≥ 100 km/h |
| Max Flight Duration with Payload | ≥ 80 minutes |
| Max Range with Payload | ≥ 30 km |
| Control Signal Transmission | Digital, 750–1050 MHz* |
| Control Protocol | ExpressLRS* |
| Video Transmission | Analog, 5658–5945 MHz* |
| Camera Resolution | ≥ 1000 TVL |
| Video Transmitter Power | ≥ 2.5 W |
| Wingspan | 1488 mm |
| Operating Temperature Range | -15°C to +40°C |
*Standard configuration
Package Contents – VB 140 Flamingo
1. FPV Fixed-Wing Drone
2. Video Antenna
3. 6S 8000+ mAh Battery
4. Packaging
