JACK KNIFE J3, J5 & J9
The CANNON Jack Knife J3, J5, and J9 are versatile, long-endurance quadcopter UAVs built from lightweight carbon fiber for durability and extended flight times.
Product descripton: JACK KNIFE J3, J5 & J9 by Cannon Dynamics
The CANNON JACK KNIFE J3, J5 and J9 are versatile, long-endurance quadcopter UAVs.
Jack knife is constructed from lightweight and durable carbon fiber material to give you a tough and strong frame but lightweight for a longer flight time.
The Jack knife comes with a flexible connector and multiple optional power supply ports for better compatibility with more devices for different demands.
Flight Modes and Propulsion
JACK KNIFE features 4 motors each with a single prop. The 4 motors have been optimised for effiecient, weight reduction and endurance for highly efficient, stable and safe flight.
Cameras and Optics
JACK KNIFE can be fitted with a range of Cannon SmartEye cameras featuring single or multiple sensors, low-light vision, IR and thermal vision, tracking and more.
All cameras are gimbal mounted, packages range from under 200g to around 2kg.Single, Dual or Triple-sensor gimbal cameras
10x to 80x Optical Zoom
Up to 32x Digital Zoom
Thermal imaging options
AI Object Tracking and more
All cameras are gimbal mounted, packages range from under 200g to around 2kg.Single, Dual or Triple-sensor gimbal cameras
10x to 80x Optical Zoom
Up to 32x Digital Zoom
Thermal imaging options
AI Object Tracking and more
Autopilot
With the autopilot mission package the JACK KNIFE can operate in autopilot mode. The JACK KNIFE can follow pre-programmed flight paths or react to responsive flight instructions.
Ground Control Stations
For human control of the JACK KNIFE UAV, Cannon can supply ground control stations.
Features
- Light weight frame – easy to carry and transport
- Rapidly deployed, convenient
- Fully integrated ISR (Intelligence, Surveillance , Reconnaissance)
- Provides quick, out of the box, flight operation
- Safe, Reliable, Stable
- Easy to operate
- Electric propulsion
- Full product support
Technical specifications
| Model | J3-50 | J5-40 | J9-24 |
|---|---|---|---|
| Dimensions (without props) | 550 x 550 x 445mm | 550 x 550 x 445mm | 550 x 550 x 445mm |
| Wheelbase | 860mm | 860mm | 860mm |
| Frame Weight | 9.96kg | 9.96kg | 9.96kg |
| Take-off Weight | 19.96kg | 19.96kg | 19.96kg |
| Frame Material | Carbon Fibre | Carbon Fibre | Carbon Fibre |
| Flight Time | 50mins (3.0kg Payload) | 40mins (5.0kg Payload) | 24mins (9.0kg Payload) |
| Payload | 3.0kg+ | 5.0kg+ | 9.0kg+ |
| Max Range | |||
| Wind Resistance | 14m/s | 14m/s | 14m/s |
| Working Temperature | -15C to 50C | -15C to 50C | -15C to 50C |
| Control Range | |||
| Cruising Speed | |||
| Max Flying Speed | 20m/s | 20m/s | 20m/s |
| Max Altitude |
