KARGUFPV Kamikaze UAV
Product descripton: KARGUFPV Kamikaze UAV by STM (Savunma Teknolojileri Mühendislik)
The KarguFPV Kamikaze Drone combines high manoeuvrability with effective day and night operation capability and a low radar cross-sectional area, facilitating precise strikes against fixed or moving targets.
Equipped with an advanced military security fuze and an integrated day and night camera, the KarguFPV Drone is resistant to electronic warfare effects such as jamming and blinding. The platform can be programmed to detonate automatically at an adjustable distance using its proximity sensor, or can be detonated manually. Its autonomous terminal diving capability, supported by computer vision, ensures accurate target marking and precise hits.
The KarguFPV Drone acts as a deterrent force against dynamic threats in asymmetric warfare environments, directed towards enemy elements with its operator-controlled real-time vision system, neutralising its target with anti-personnel ammunition.
KARGU FPV, which provides a deterrent capability against dynamic threats in asymmetric warfare environments, engages enemy elements through its operator-controlled real-time vision system and neutralizes its target using its onboard anti-personnel munition.
Payload Options
- Anti-Personnel Warhead
- Armor-Piercing Warhead
- Fiber-Optic Cable
In addition to its anti-personnel warhead, KARGUFPV has also been equipped with an armor-piercing warhead to ensure high effectiveness against armored targets. The fiber-optic cable enables secure and uninterrupted data transmission, allowing real-time operator control even in enclosed and complex environment.
Technical specifications
Capabilities | Competencies
- Precision strike capability
- Object Tracking of moving targets
- Low Radar Cross Section
- Day and Night Operation
- Electronic, mechanical and software safe Fuze System
- Proximity Sensor
- Automatic detonation at an adjustable distance
- Anti-personnel optimized area effect munition
- Autonomous terminal diving with computer vision
- Day light/Thermal integrated camera
- Jamming-resistant 2 distinct data link
- Safe Mission Abort and Landing
- Safe Manually Return-to-Home Function
- Anti-Personnel Optimized Area Effect Munition
Warhead or Armor-Piercing Warhead
| Parameter | Specification |
|---|---|
| Mission Range | 10 km |
| Endurance | 20+ min kamikaze mode (Kargu ammunition & fuze)44 min observation mode (without ammunition & fuze) |
| Mission Altitude | 500 m (AGL) |
| Maximum Altitude | 5,500 m (MSL) |
| Warhead | With fuze, 1,300 gr Anti-Personnel |
| Maximum Speed | 160 km/h |
| Platform Dimensions | 355 × 355 × 300 mm |
| Platform Take-off Weight | 3,650 gr (with 1.3 kg ammunition) |
| Wind Resistance | 30 m/s |
| Operating Temperature Conditions | −20 to +60 °C |
| Power | Lithium-Ion Battery |
