Sensus D12
Product descripton: Sensus D12 by ISS Aerospace
The Sensus D12 is a high-performance photography drone designed specifically for the demands of the cinema and film production industries. The world’s fastest heavy-lift cinematic drone. Engineered for all-weather professional use, the D12 offers incredible versatility, carrying heavy payloads of up to 20kg.
Whether you’re capturing breathtaking aerial shots or navigating complex terrain, the Sensus D12’s robust build, and advanced features make it the ideal choice for cinematic photography and videography. It’s perfect for feature films, documentaries, commercials, adventure, and drama productions.
The Sensus D12 drone is built for the demands of professional filmmaking, offering rock-solid stability and the power to carry heavy payloads of up to 20kg. Compatible with gimbals such as the Movi Pro and Ronin 2, it easily supports high-end cameras such as the RED Helium 8K, ARRI Alexa Mini, and Canon C300 etc, ensuring smooth, cinematic shots from the sky.
Gimbal Ready
Equipped with a capable FPV camera, the Sensus D12 is designed to support Movi Pro, RONIN 2, and other heavy-lift cinema gimbals.
Payload Capacity — 20.0 kg
Built to handle a wide range of professional camera setups, the Sensus D12 can support payloads up to 20 kg, making it fully adaptable to diverse cinematic requirements.
Maximum Range — 40.0 km
With a flight range of 40 km, the system enables long-distance operations and effortless capture of footage from far-reaching locations.
Maximum Speed — 150.0 kph
Rated IP64 for weather protection and capable of reaching speeds of 150 kph, the Sensus D12 delivers fast, powerful performance suitable for even the most demanding tasks.
Technical specifications
Key Features
-
Range of up to 40 km (24 miles)
-
Payload capacity of 15 kg – 20 kg
-
Maximum flight speed of up to 150 kph
-
Industry-leading GNSS and autopilot system
-
Integrated obstacle avoidance system
-
Built to support Movi Pro and Ronin 2 gimbals
-
IP64 environmental rating
-
Wind resistance of up to 80 kph
-
FPV pilot camera
-
FPV and live video feed to ground station
Technical Specifications
| Specification | Value |
|---|---|
| Dimensions (Span) | 1,300 mm (with props) / 973 mm (without props) |
| Dimensions (Height) | 400 mm (without payload) |
| Weight | 7.0 kg (excluding batteries) |
| Maximum Take-off Weight | 25.0 kg (including batteries) |
| Maximum Payload Capacity | 20.0 kg |
| Maximum Pitch Angle | 45° |
| Maximum Ascent Speed | 18.0 kph (5 m/s) |
| Maximum Descent Speed | 7.0 kph (2 m/s) |
| Maximum Flight Speed | 150.0 kph (42 m/s) |
| Maximum Wind Resistance | 80.0 kph (22 m/s) |
| Maximum Flight Time | 20 mins (no payload) / 10 mins (max payload) |
| Maximum Range | 40 km (24 miles) |
| IP Rating | IP64 |
| Operating Temperatures | –19°C to +55°C (–2°F to +131°F) |
