SNOOP 18
Product descripton: SNOOP 18 by Cannon Dynamics
The SNOOP 18 is a versatile VTOL fixed-wing UAV designed for long-endurance missions and extended flight times.
Durability & Versatility
SNOOP 18 offers a robust, durable platform with flexible capabilities, making it suitable for a variety of operational scenarios.
Design & Performance
As an electric-driven VTOL UAV with a fixed-wing configuration, the SNOOP 18 combines power and efficiency with a lightweight frame, ensuring excellent flight characteristics and reliable performance.
The CANNON SNOOP is a long-endurance VTOL fixed wing UAV with long flight times.
CANNON SNOOP is equipped with a power management module, locking propeller function, as well as lightweight and durable carbon fiber material to give you a longer flight time.
The SNOOP is available in 2 wingspans, 1.7m and 2.3m.
Featuring a tilt-rotor design the SNOOP 18 combines the benefits of both vertical take-off and landing (VTOL) with efficient fixed-wing cruising.
SNOOP is adaptable for a diverse range of applications that require both flexibility and endurance.
Features
- Combines vertical take-off and landing with fixed wing flight efficiency
- Complete, Switch and Go
- Light weight frame – easy to carry and transport
- Rapidly deployed, convenient
- Fully integrated ISR (Intelligence, Surveillance , Reconnaissance)
- Provides quick, out of the box, flight operation
- Safe, Reliable, Stable
- Easy to operate
- Electric propulsion
- Full product support
Technical specifications
| Model | CANNON SNOOP – SNP 18 |
|---|---|
| Frame Length | 1310mm |
| Wingspan | 1700mm |
| Frame Weight | |
| Take-off Weight | 5.5kg |
| Frame Material | Carbon Fibre and EPP |
| Flight Time | 150mins (No Payload) 120mins (0.8kg Payload) |
| Payload | 0.9kg |
| Max Range | 125km |
| Wind Resistance | Level 5 |
| Working Temperature | -10C to 40C |
| Control Range | 10 – 30km |
| Cruising Speed | 15 – 18m/s |
| Max Flying Speed | 25m/s |
| Max Altitude | 4500m |
| Recommended Battery | 8s, 14500mah |
