SPARK

Takeoff Weight 300 g Dimensions 143×143×55 mm Diagonal Distance (propellers excluded) 170 mm Max Ascent Speed 9.8 ft/s (3 m/s) in Sport Mode without wind Max Descent Speed 9.8 ft/s (3 m/s) in Auto Landing Mode Max Speed 31 mph (50 kph) in Sport Mode without wind Max Service Ceiling Above Sea Level 13,123 feet (4,000 m) Max Flight Time 16 minutes (no wind at a consistent 12.4 mph (20 kph)) Max Hovering Time 15 minutes (no wind) Operating Temperature Range 32° to 104° F (0° to 40° C) Satellite Positioning Systems GPS/GLONASS Hover Accuracy Range Vertical: +/- 0.1 m (when Vision Positioning is active) or +/-0.5 m Horizontal: +/- 0.3 m (when Vision Positioning is active) or +/-1.5 m Transmitter Power (EIRP) 2.4 GHz FCC: 25 dBm; CE: 18 dBm; SRRC: 18 dBm; MIC:18 dBm 5.8 GHz FCC: 27 dBm; CE: 14 dBm; SRRC: 27 dBm; MIC: – Operating Frequency 2.400 – 2.483 GHz; 5.725 – 5.825 GHz Gimbal Controllable Range Pitch: -85° to 0° Stabilization 2-axis mechanical (pitch, roll) 3D Sensing system Obstacle Sensing Range 1-16 ft (0.2 – 5 m) Operating Environment Detects diffuse reflective surfaces (>20%) larger than 20×20 cm (walls, trees, people, etc.) Vision System Velocity Range ≤22.4 mph (36 kph) at 6.6 ft (2 m) above ground Operating Range 0-98 ft (0 – 30 m) Operating Environment Detects clearly patterned surfaces with adequate lighting (lux>15) and diffuse reflectivity (>20%) Camera Sensor 1/2.3″ CMOS Effective pixels: 12 MP Lens FOV 81.9° 25 mm (35 mm format equivalent) f/2.6 (shooting range: 2 m to ∞) ISO Range Video: 100-3200 Photo: 100-1600 Electronic Shutter Speed 2-1/8000 s Image Size 3968×2976 1440×1080 with ShallowFocus
