STREAM C VTOL
Product descripton: STREAM C VTOL by Threod Systems
Stream C VTOL is a highly capable VTOL UAV with best in class flight performance and many unique features
– Provides exceptional image quality from high altitudes
– Efficient, reliable and safe VTOL take-off and landing transitions
– Protected main payload bay
– High wind penetration capability
– Reliable engine with in-flight restart capability
– MESH network radio with full Interoperability
– Secondary data-link option
– Several payload bays and mounts for custom sensors and equipment
– Large variety of ground equipment available for UAS solution
Technical specifications
PERFORMANCE
Over 6 hours
Operational up to 3000m AGL
80-130 km/h
Catapult launch, parachute recovery
Lift capacity 6kg
MULTISENSOR PACKAGE
Cooled MWIR gimbal
EO sensor
MWIR sensor
Laser rangefinder
Aerial mapping payload
50MP aerial mapping sensor
COMMUNICATIONS
Dual-frequency
Over 150 km LOS
AES-256
MESH network
Voice, video, data
ISR
720p HD live streaming
Reporting tool
KLV metadata
Selectable recording
