Swift Short Range SSR-AT
Product descripton: Swift Short Range SSR-AT by Swiftships
The SSR-AT is a compact fixed-wing aerial target UAV developed for military training, target simulation, and electronic warfare exercises. Designed for flexible deployment, it launches from portable systems, RATO, or vehicles and is controlled via an integrated autopilot with real-time datalink to a handheld ground control station.
Its modular payload system enables the aircraft to simulate diverse airborne threats while supporting decoy operations, electronic warfare training, and advanced target presentation. The platform accommodates IR signature enhancers, electronic jammers, transponders, chaff dispensers, and EW pods, providing realistic and adaptable training scenarios.
Key Features
Advanced Target Simulation
- Dedicated aerial target platform
- Supports realistic threat replication for live-fire and training exercises
Flexible Deployment
- Portable launcher, RATO, or vehicle launch
- Conventional or parachute recovery
Autonomous Flight Operations
- Integrated autopilot system
- Video, GPS, and real-time datalink
- Suitable for coordinated swarm training missions
Electronic Warfare Training
- Compatible with electronic jammers
- IR signature enhancement
- Chaff dispensing
- Tracking transponders
- EW training payloads
Extended Mission Endurance
- Up to 8 hours of flight endurance
- Long-range operation for prolonged training missions
Technical specifications
| Specification | SSR-AT |
|---|---|
| Role | Aerial Target |
| Type | Fixed-Wing UAV |
| Length | 2.8 m (9.2 ft) |
| Wingspan | 3.0 m (9.8 ft) |
| Maximum Takeoff Weight | 30–40 kg (66.1–88.1 lb) |
| Range | 100–150 km (62.1–93.2 mi) |
| Speed Range | 54–108 knots |
| Launch Method | Launcher / RATO / Vehicle Launch |
| Power Plant | IC Engine |
| Endurance | 6–8 hours (payload dependent) |
| Recovery | Conventional Landing / Parachute |
| Service Ceiling | 3,657 m (12,000 ft) |
| Flight Control | Integrated Autopilot System |
| Tracking & Telemetry | Video, GPS, and datalink module with handheld ground control station |
| Typical Payloads | Swarming modules, IR signature enhancers, chaff dispensers, electronic jammers, tracking transponders, EW pods |
